efus™A9X
Computer On Module with NXP i.MX 6SoloX CPU
|
|
 For the start of development, we recommend: |
| efus™A9X | ||
| State | Production | |
| CPU | ||
| CPU | NXP i.MX 6SoloX | |
| Core | ARM Cortex-A9 + Cortex-M4 | |
| No of Cores | 1 + M4 | |
| Frequency | max. 1GHz + 200MHz | |
| L2-Cache | 256KB | |
| GPU | 2D, 3D | |
| Operating System | ||
| Android | Lollipop 5.1.1 | |
| Linux | Buildroot Yocto (uboot installed) |
|
| Windows | WEC 2013 (Bootloader installed) |
|
| Real Time | FreeRTOS | |
| Memory | ||
| Flash | max. 512MB | |
| eMMC | max. 32GB | |
| RAM | max. 2GB | |
| Interfaces | ||
| SD-Card | 2x extern | |
| Ethernet | 2x 100/1000Mb | |
| WiFi | IEEE802.11 b/g/n/ac* | |
| BT | BT 2.1+EDR 4.0/4.1 with antenna socket opt. chip antenna |
|
| USB Host | 1x | |
| USB Device | 1x | |
| CAN | 2x | |
| UART | 4x | |
| I2C | 2x | |
| SPI | 2x | |
| Audio | I2S | |
| Touch Panel | analog resitive and PCAP Touch ext. via I2C | |
| Camera analog/digital | 1/Parallel 8bit | |
| PCIe | 1x | |
| RTC | on board/ external IC | |
| Display | ||
| RGB | 18bit | |
| LVDS | 1x 24bit opt. 1x 18bit LVDS via MXM2 |
|
| Common | ||
| Supply Voltage | +5VDC/ ±5% | |
| Power Consumption | 2W typ. | |
| Operating Temperature | 0°C - +70°C opt. -20°C - +85°C |
|
| Size | 47x62.1x11mm (lxbxd) |
|
| Weight | ~15g | |
| Long Term Availability | 2035 |
| efus™A9Xr2-V2-LIN | efus™A9Xr2-V2-W13 | efus™A9Xr2-V4-LIN | efus™A9Xr2-V4-W13 | efus™A9Xr2-V5-LIN/-W13 | efus™A9X-V8-W13 | |
| State | Production | Production | Production | Production | Production | Production |
| CPU | - | - | - | - | - | - |
| CPU | NXP i.MX 6SoloX | NXP i.MX 6SoloX | NXP i.MX 6SoloX | NXP i.MX 6SoloX | NXP i.MX 6SoloX | NXP i.MX 6SoloX |
| Core | ARM Cortex-A9 + Cortex-M4 | ARM Cortex-A9 + Cortex-M4 | ARM Cortex-A9 + Cortex-M4 | ARM Cortex-A9 + Cortex-M4 | ARM Cortex-A9 + Cortex-M4 | ARM Cortex-A9 + Cortex-M4 |
| No of Cores | 1 + M4 | 1 + M4 | 1 + M4 | 1 + M4 | 1 + M4 | 1 + M4 |
| Frequency | 1000MHz + 200MHz | 1000MHz + 200MHz | 1000MHz + 200MHz | 1000MHz + 200MHz | 1000MHz + 200MHz | 1000MHz + 200MHz |
| L2-Cache | 256KB | 256KB | 256KB | 256KB | 256KB | 256KB |
| GPU | 2D, 3D | 2D, 3D | 2D, 3D | 2D, 3D | 2D, 3D | 2D, 3D |
| Operating System | - | - | - | - | - | - |
| Linux | Buildroot Yocto (uboot installed) |
- | Buildroot Yocto (uboot installed) |
- | Buildroot Yocto (uboot installed) |
- |
| Windows | WEC 2013 (Bootloader installed) |
WEC 2013 (Bootloader installed) |
WEC 2013 (Bootloader installed) |
WEC 2013 (Bootloader installed) |
WEC 2013 (Bootloader installed) |
WEC 2013 (Bootloader installed) |
| Real Time | FreeRTOS | FreeRTOS | FreeRTOS | FreeRTOS | FreeRTOS | FreeRTOS |
| Memory | - | - | - | - | - | - |
| Flash | 256MB | 256MB | 256MB 4GB eMMC |
256MB 4GB eMMC |
256MB | 512MB |
| eMMC | max. 32GB | max. 32GB | max. 32GB | max. 32GB | max. 32GB | max. 32GB |
| RAM | 512MB | 512MB | 1GB | 1GB | 512 MB | 512MB |
| Interfaces | - | - | - | - | - | - |
| SD-Card | 2x extern | 2x extern | 1x extern | 1x extern | 1x extern | 1x extern |
| Ethernet | 2x 100/1000Mb | 2x 100/1000Mb | 2x 100/1000Mb | 2x 100/1000Mb | 1x 100/1000Mb | 1x 100/1000Mb |
| WiFi | - | - | IEEE802.11 b/g/n/ac* | IEEE802.11 b/g/n/ac* | IEEE802.11 b/g/n/ac* | IEEE 802.11 b/g/n/ac |
| BT | - | - | BT 2.1+EDR 4.0/4.1 with antenna socket | BT 2.1+EDR 4.0/4.1 with antenna socket | BT 2.1+EDR 4.0/4.1 with antenna socket | BT 2.1 + EDR, 4.x LE with chip antenna |
| USB Host | 1x | 1x | 1x | 1x | 1x | 1x |
| USB Device | 1x | 1x | 1x | 1x | 1x | 1x |
| CAN | 2x | 2x | 2x | 2x | 2x | 2x |
| UART | 4x | 4x | 4x | 4x | 4x | 4x |
| I2C | 2x | 2x | 2x | 2x | 2x | 2x |
| SPI | 2x | 2x | 2x | 2x | 2x | 2x |
| Audio | I2S | I2S | I2S | I2S | I2S | I2S |
| Touch Panel | analog resitive and PCAP Touch ext. via I2C | analog resitive and PCAP Touch ext. via I2C | analog resitive and PCAP Touch ext. via I2C | analog resitive and PCAP Touch ext. via I2C | analog resitive and PCAP Touch ext. via I2C | analog resitive and PCAP Touch ext. via I2C |
| Camera analog/digital | 1/Parallel 8bit | 1/Parallel 8bit | 1/Parallel 8bit | 1/Parallel 8bit | 1/Parallel 8bit | 1/Parallel 8bit |
| PCIe | 1x | 1x | 1x | 1x | 1x | 1x |
| RTC | external IC | extern IC | extern IC | external IC | external IC | external IC |
| Display | - | - | - | - | - | - |
| RGB | 18bit | 18bit | 18bit | 18bit | 18bit | 18bit |
| LVDS | 24bit | 24bit | 24bit | 24bit | 24bit | 24bit |
| Common | - | - | - | - | - | - |
| Supply Voltage | +5VDC/ ±5% | +5VDC/ ±5% | +5VDC/ ±5% | +5VDC/ ±5% | +5VDC/ ±5% | +5VDC/ ±5% |
| Power Consumption | 2W typ. | 2W typ. | 2W typ. | 2W typ. | 2,5W typ. | 3W typ. |
| Operating Temperature | 0°C - +70°C | 0°C - +70°C | 0°C - +70°C | 0°C - +70°C | 0°C - +70°C | 0°C - +70°C |
| Size | 47x62.1x11mm (lxbxd) |
47x62.1x11mm (lxbxd) |
47x62.1x11mm (lxbxd) |
47x62.1x11mm (lxbxd) |
47x62.1x11mm (lxbxd) |
47x62.1x11mm (lxbxd) |
| Weight | ~15g | ~15g | ~15g | ~15g | ~15g | ~15g |
| Long Term Availability | 2035 | 2035 | 2035 | 2035 | 2035 | 2035 |
| efus™A9Xr2-V2-LIN | efus™A9Xr2-V2-W13 | efus™A9Xr2-V4-LIN | efus™A9Xr2-V4-W13 | efus™A9Xr2-V5-LIN/-W13 | efus™A9X-V8-W13 |
 |
Starterkit efus™A9X Linux efusA9X-V4-LIN, base board, cable kit, 7" EDT RGB TFT with resistive touch incl. adapter and cables, access data to documentation and software SKU: efusA9X-SKIT-LIN |
360,- € | ||
 |
Starterkit efus™A9X Windows efusA9X-V4-W13, base board, cable kit, 7" EDT RGB TFT with resistive touch incl. adapter and cables, access data to documentation and software SKU: efusA9X-SKIT-WCE |
360,- € |
Software
 |
Software .NET Drivers Driver package for retrofitting, consists of C# drivers for I²C/ SPI/ CAN, as well as the SPI driver in C++. SKU: WCE-DOTNET |
500,- € | ||
|
UpDate Software This program package allows a safe and easy update of the application program and the operating system via USB Stick or SD Card. SKU: WCE-UPDATE |
500,- € | ||
|
Boot Screen Shows the device's user a starting procedure while booting (BMP File). SKU: WCE-BOOTSCREEN |
500,- € | ||
|
Custom Kernel Creation of a customer-specific kernel. Windows CE components are set as the customer requests, as well as the registry entries (e.g. display). Customer-supplied software can also be added. SKU: WCE-CUSTIMAGE |
500,- € | ||
|
Failsafe Flash Filesystem (F3S) The Failsafe Flash Filesystem F3S offers transaction safety on file level and therefore guarantees the consistency of the data, even in case of a blackout or other interferences while writing. SKU: WCE-F3S |
1,000,- € | ||
|
Secure Boot as a Service The SBS (Secure Boot as a Service) includes the signing (protection against manipulation) and if necessary encryption (protection of intellectual property) by F&S Elektronik Systeme. SKU: Linux-SBS |
500,- € | ||
|
Display Customization (RGB or LVDS display under Linux) Creation of a DeviceTree (Buildroot or Yocto) for your F&S Board. The DeviceTree contains the appropriate entries for your display. SKU: EW-SW |
700,- € | ||
|
Display Customization (MIPI-DSI Display under Linux) Creation of a DeviceTree / kernel (Buildroot or Yocto) for your F&S Board. The DeviceTree / kernel contains the appropriate entries for your MIPI-DSI display. SKU: EW-SW-MIPI-DSI-Linux |
1,000,- € | ||
|
Display Customization (RGB orLVDS Display under Windows) Creation of a driver for the touch controller under WCE7 or WEC13 for your F&S board. SKU: EW-SW-RGB-LVDS-Windows |
500,- € |
Displays and Display Kits
 |
7" RGB Display with resistive Touch 7" TFT (800x480) EDT ET070080DH6 SKU: B.LCD.15 |
120,- € | ||
 |
7" RGB Display with PCAP Touch 7" TFT (800x480) Display Endrich MI0700AJT-54CP with capacitive Touch SKU: B.LCD.18 |
150,- € | ||
 |
Displaykit RGB 2 7" WVGA Display with RGB interface and touch panel, connection cable (40pol film cable), display adapter and touch cable SKU: aSt-RGBKIT |
170,- € | ||
 |
Displaykit 7" RGB - PCAP Touch 7" Display with RGB interface and capacitive touch panel, connection cable (50pol film cable) and display adapter. SKU: KIT-TFT-7RGB |
210,- € |
Touch Kits
 |
Resistive Touch Kit For connecting a resistive Touch panel to F&S boards with 4-poles touch connector. SKU: SINTF-ADP-RESTOUCH |
35,- € | ||
 |
PCAP Touch Kit for EDT Kit to connect an EDT PCAP touch panel SKU: ADP-EDTTOUCH2 |
35,- € |
Cables
 |
50poles Film Cable Cable for 7" RGB Endrich Display (B.LCD.18) FFC cable, A50pol., pitch=0,5mm, l=200mm SKU: B.MKAB.41 |
10,- € | ||
 |
LVDS Cable LVDS cable with JAE FI X30 on one side and open ends on the other side SKU: B.MKAB.53 |
22,- € |
Adapters
 |
I2C Erweiterung Circuit for an external extension with GPIOs, AID, PWM and matrix keyboard. This external circuit is connected via I²C Bus. SKU: NDCU-ADP/I2C |
80,- € | ||
 |
JTAG Debug Adapter To program Cortex-M4. SKU: ADP-CMSIS |
69,- € | ||
 |
armStone™/ efus™/ PicoCore™ DVI Adapter Connects armStone™, efus™ or PicoCore™ to a DVI/ HDMI screen. SKU: aStone-ADP-DVI |
50,- € | ||
 |
Adapter for Endrich iSi50 Displays Adapter to connect Endrich iSi50 displays to F&S boards SKU: aSt-ADP-MIT1 |
50,- € | ||
 |
mPCIe Module with WLAN/BT mPCIe-Full-Mini Type F1 or mPCIe-Half-Mini Type H1 module with WLAN 2.4/ 5 GHz und BT5.0 LE SKU: ADP-mPCIe-WLAN |
40,- € |
Plug Connector
 |
MXM-2 Connector For connecting efus™- or QBliss-modules via goldfinger contacts. SKU: B.MST.2R230PL.1 |
43,- € |
Workshops
 |
Workshops Workshops for F&S Boards with Windows Embedded Compact or Linux - Beginner Workshops - Qt 5 - Asymmetric Multiprocessing - Secure Boot SKU: NDCU-WS1 |
Request | ||
|
Secure Boot as a Package Secure Boot as a Package contains a workshop, where you learn how to realize the topic Secure Boot. You will also receive a user Tool Software. SKU: WS-SBP |
500,- € | ||
Other Accessories
 |
USB Stick USB Memory Stick with common memory size (2GB+) and imprinted F&S logo. The USB Stick was tested on all current F&S boards. SKU: USBSTICK.1 |
20,- € | ||
 |
efus™ Latch Allows to mount efus™ modules on the base board. SKU: B.MST.VR.5 |
36,- € | ||
 |
Patch Antenna Patch antenna for WLAN/ BT (2.4 GHz) to connect F&S modules with WLAN/ BT antenna socket SKU: B.ANT.5 |
10,- € |
Buildroot and Yocto
The Linux BSP "fsimx6sx-B2024.01" is based on Buildroot, a software for creating root file systems. About 1400 different software packages can be added to the root file system using menu control. The range of functions ranges from simple libraries and utilities to a complete Java environment to complete graphical environments such as Qt or Wayland/Weston, including applications such as an HTML5-capable web browser. In this way, it is very easy to put together a customized Linux system.
As an alternative to Buildroot, there is also a Yocto-based environment. We offer the Linux BSP fsimx6sx-Y2020.03, which is based on Yocto.
Our standard configuration, which should give a first impression of the functional scope of the module, contains the following features: Busybox, gdb, alsa-utils, gstreamer, wayland-weston, feh, openssl, openssh, ncurses, can-utils, iproute2, ftpd, httpd, telnet, tftp, and much more
Both BSPs include the source code packages from U-Boot (2021.04), Linux kernel (based on 5.15.131) and Buildroot (2023.02.06) or Yocto (4.0) adapted by F&S. In addition, our cross toolchain is included, some sample applications and all binaries in the standard configuration. And last but not least, detailed documents on the hardware are included as well as the first steps documentation for easy entry.
F&S also offers a virtual machine (based on VirtualBox) with an installed Linux based on the Fedora 36 distribution for free download. All packages necessary to translate our software are already installed. All services (NFS, TFTP) for working with our boards are also installed. Our BSP is unpacked and precompiled in the right directories. With this virtual machine it doesn't matter whether you use Windows or Linux as the host. Simply download the VHD, import it into VirtualBox and development can begin immediately.
➜ More information about the new Buildroot Release B2024.01
➜ More information about the new YOCTO release Y2020.03
Windows Embedded Lifetime
| Feature | Available until | End of Mainstream Support | End of Extended Support |
| Windows Embedded Compact 2013 | 31.05.2028 | 10.09.2018 | 10.10.2023 |
| Windows Embedded Compact 7 | 28.02.2026 | 12.04.2016 | 13.04.2021 |
| Windows CE 6.0 | 28.02.2022 | 09.04.2013 | 10.04.2018 |
Windows Embedded Compact 7
Windows Embedded Compact 7 offers bootloaders, kernels (e.g. with Silverlight, Mediaplayer or IE) and interface drivers for almost every offered interface are ready to use.
Hard work with platform builder can be dropped, we already did that for you.
Create your software with Visual Studio .NET in the languages C, C++, C# or VB.NET.
Use interfaces like I²C the same way like a RS232 interface without having to handle the underlying hardware.
Configure the display and other settings with the F&S configuration tool.
Windows Embedded Compact 2013
The highly flexible and hard real-time operating system has kernel, interface drivers and bootloader. It benefits from all the features of a modern CPU, such as ARMv7 THUMB2 command structure or NEON co-processor.
Complete images and the BSP are available in our download area.
Development is done with the latest Microsoft tools like Visual Studio 2015 (C, C++, C# or VB.NET) and Expression Blend 5.
Interfaces like I²C, CAN or SPI can be used in the same way like a RS232 interface.
XAML for Windows Embedded helps to separate visualisation and program the easy way.
Our FailSafe Flash File System F3S is also available in Compact 2013.
Windows Embedded Features for i.MX6
General
| Feature | Description | i.MX6 | WEC 2013 |
| .NET Support | Library to easily access DIO, CAN, I²C and SPI from .NET Compact Framework | ✔ | ✔ |
| AnalogIn | Stream driver to easily access the analog inputs | ✔ | ✔ |
| Audio Codec | Support for Microphone, LineIn and LineOut. Implements Mixer interface and special F&S mixer control panel applet to easily change settings. |
✔ | ✔ |
| BusEnum2 | Support for asynchronous loading of drivers. Use events to start loading of drivers. | ✔ | ✔ |
| Broadcast | Stream driver Boards can be easily identified and configured over LAN connection |
✔ | ✔ |
| CAN | Stream driver to easily access CAN interface. Special tool suit to generate traffic or check communication. | ✔ | ✔ |
| Digital I/O | Stream driver to configure pins as input, output or interrupt. Possibility to adjust drive strength or enable/disable internal pull-up or pull-down. Settings can be stored pin registry. |
✔ | ✔ |
| Display | Display driver can be configured by registry settings without modifying operating system. | ✔ | ✔ |
| Display | Multi-Monitor Support Adjustable by registry |
✔ | ✔ |
| Display | 2D software acceleration using NEON co-processor Multiple overlays with alpha blending |
✔ | ✔ |
| Display | 2D hardware acceleration 3D OpenGL ES 1.1 and 2.0 hardware acceleration Multiple overlays with alpha blending Multiple monitor support (incl. 2D acceleration and Video support) |
✔ | ✔ |
| Firmware Update | Software to update Bootloader and/or operating system from running operating system. | ✔ | ✔ |
| Software Update | Program to update application and registry settings from USB stick, SD card or other source. Includes automatic detection. Can incorporate with Firmware Update |
✔ | ✔ |
| I²C | Stream driver Support for hardware I²C controller (NI2C) Support for using GPIOs as I²C (I²C) |
✔ | ✔ |
| Keyboard | Support for German 0407, Spanish 040A, French 040C, Italy 0410 and English 0409 Matrix keyboard support: Use IO pins for keyboard |
✔ | ✔ |
| SPI | Stream driver Support for hardware SPI controller |
✔ | ✔ |
| Touch | Resistive touch driver with virtual key support - Capacitive touch driver for ATMEL EDT and others Extended USB mouse driver to accept absolute coordinates |
✔ | ✔ |
| USB Host | EHCI and OHCI driver | ✔ | ✔ |
| USB Device | ✔ | ✔ | |
| KBDHID | Extended MS kbdhid - Support for all keys on the keyboard | ✔ | ✔ |
| MOUTOUCHHID | Support for absolute coordinates | ✔ | ✔ |
| Power Management | Support for screen saver and touch activation | ✔ | ✔ |
| PWM | Stream driver | ✔ | ✔ |
| Video Streaming | Filter framework for streaming video over HTTP | ✔ | ✔ |
| VoIP | Voice over IP sample solution | ✔ |
File System
| Feature | Description | i.MX6 | WEC 2013 |
| F&S BinFS | Bug fixed BinFS file system for XIP images | ✔ | ✔ |
| F3S | F&S Secure Flash File System Optimized throughput on all file operations Wear-Leveling strategies to reduce flash abrasion (including Garbage Collector) Transaction-based concept already cooperates with a lot of applications |
✔ | ✔ |
| Filesystem Filter Driver |
Used to limit access to file system. Possible restrictions: Move, Delete, Rename |
✔ | ✔ |
| FAT/TFAT | Microsoft Windows Embedded FAT/TFAT solution. | ✔ | ✔ |
| NAND Driver | 16 bit hardware ECC | ✔ |
Services
| Feature | Description | i.MX6 | WEC 2013 |
| Telnet Server | Enabled by default. Easy access to command shell. | ✔ | ✔ |
| FTP Server | ✔ | ✔ | |
| HTTPD Server | Use device as web server. Create ISAPI extensions in C/C++. HTTPD DirectShow stream filter (i.e. camera) | ✔ | ✔ |
| OpenSSH | Offers SSH server functionality for Windows Embedded. Based on OpenSSH SFTP SCP SMTP |
✔ | ✔ |
| SSH SCP/SFTP server | SSH Library (also used from SMTP). | ✔ | ✔ |
| SMTP | SMTP library to send EMail | ✔ | ✔ |
Tools
| Feature | Description | i.MX6 | WEC 2013 |
| Bootscreen | Showing custom image during boot. | ✔ | ✔ |
| Control Panel | Standard Windows Embedded Control Panel with additional tools. | ✔ | ✔ |
| CE Remote Display | Driver and application to access desktop of device remotely. | ✔ | ✔ |
| ndcucfg | Command line configuration tool. Can be used locally, over Telnet connection and over serial connection. Registry editing Reading/writing of boot loaders and splash screen User administration Certificate administration .... Usage: * Can be used in own applications as DLL. * As a command line tool from telnet or serial debug console |
✔ | ✔ |
| Update tool | Update of boot loader Update on WinCE image Registry changes Update of user application Runs from SD/USB/LAN |
✔ | ✔ |
| F&S 2D control utility | Control panel applet Change 2D acceleration on the fly |
✔ | ✔ |
| F&S Board Config | Control panel applet Check hardware revision, version of boot loader, version of WinCE image and much more. Change system startup and registry. |
✔ | ✔ |
| F&S Audio Mixer | Control panel applet Change audio features like volume, bass, treble, input ... |
✔ | ✔ |
| F&S SSH/SMTP control utility | Control panel applet Start stop SSHD service Send test EMail by SMTP |
✔ | ✔ |
| F&S USB Loader | Uses USB device connection to update Bootloader, operating system, boot screen, configuration information, partition information. Can be used to update software or to automate production. |
✔ | ✔ |
| F&S Mfg Tool | Modified NXP Tool for board bring up and software installation | ✔ | ✔ |
efusA9X - Product Flyer
- English (469 KB, pdf) - 20/02/2024
- efus Standard (678 KB, pdf) - 30/10/2015
- Customer Specific Boards (93 KB, pdf) - 20/09/2017
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
efusA9X - Hardware
- efusA9X Hardware Documentation (2.4 MB, pdf) - 25/10/2022
- 3D Step Model (1.9 MB, zip) - 09/07/2024
- efusA9X Starterkit Hardware Documentation (3.7 MB, pdf) - 18/09/2020
- Starterkit Design Files (1.2 MB, zip) - 21/09/2020
- Design Guide (918 KB, pdf) - 15/04/2019
- Letter of Conformity (361 KB, pdf) - 07/03/2018
- NXP NBoot Programming (924 KB, pdf) - 12/10/2015
- RF Declaration Australia (304 KB, pdf) - 21/12/2020
- RF Declaration New Zealand (245 KB, pdf) - 21/12/2020
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
efusA9X - Linux
- efusA9X Linux First Steps (2 MB, pdf) - 01/02/2024
- Advice for Linux on PC (2 MB, pdf) - 10/01/2018
- GPIO Reference Card (139 KB, pdf) - 13/10/2017
- Quickstart with FS Development Machine (1 MB, pdf) - 06/05/2020
- Application Development with Eclipse (2.4 MB, pdf) - 18/10/2022
- Application Development with Crank (485 KB, pdf) - 28/07/2022
- Application Development with QT (2.1 MB, pdf) - 16/01/2024
- Steps Required For Creating A Progress Bar In Linux (473 KB, pdf) - 12/07/2019
- Linux on F&S Boards (2.9 MB, pdf) - 20/12/2023
- Mono on F&S Boards (2.6 MB, pdf) - 17/11/2023
- DOTNET on F&S Boards (1.1 MB, pdf) - 19/06/2024
- Visual Studio Code C/C++ Application Development (455 KB, pdf) - 29/05/2024
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
efusA9X - Windows Embedded CE/Compact
- efusA9 First Steps (2.1 MB, pdf) - 18/03/2015
- i.MX6 Device Driver (4.6 MB, pdf) - 02/03/2021
- CAN Device Driver (967 KB, pdf) - 23/03/2015
- I2C Device Drivers I2C+NI2C (393 KB, pdf) - 13/01/2017
- SPI Device Driver NSPI (2.2 MB, pdf) - 13/03/2013
- FTP Server Configuration (15 KB, pdf) - 30/12/2004
- TCP/IP Parameter (37 KB, pdf) - 30/12/2004
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
efusA9X - FreeRTOS
- Documentation (1.3 MB, pdf) - 20/12/2019
Usage
By downloading you accept our general terms and conditions.
Sorry, there are no files to show.
efusA9X - Display
- Display Settings from Datasheet (11 KB, pdf) - 19/11/2009
- Display - Pin assignment list (1.5 MB, pdf) - 07/03/2012
- Display - Settings
-
- LMT-101-9AL-PSA1U, 1280x800 Pixel (731 bytes, txt) - 21/07/2016
- CHIMEI
- CHIMEI G070Y2, 800x480 Pixel (754 bytes, txt) - 09/02/2016
- CHIMEI G070Y2, 800x480 Pixel (1.6 KB, txt) - 13/04/2016
- EDT
- EDT ET043000DH6, 480x272 Pixel (752 bytes, txt) - 04/03/2016
- EDT ET070080DH6, 800x480 Pixel (721 bytes, txt) - 29/09/2015
- EDT ETM043005BDK6, 480x272 Pixel (754 bytes, txt) - 16/03/2016
- EDT ETM070001ADH6, 800x480 Pixel (810 bytes, txt) - 04/08/2016
- EDT ET070081ADH6, 800x480 Pixel (728 bytes, txt) - 25/05/2016
- EDT ETML10100ADH6, 1024x600 Pixel (763 bytes, txt) - 04/08/2016
- EDT ETML101001DKA, 1280x800 Pixel (761 bytes, txt) - 04/08/2016
- EDT ETML121000DHA, 1280x800 Pixel (761 bytes, txt) - 04/08/2016
- EDT ETMV570G2DHU_, 640x480 Pixel (792 bytes, txt) - 13/05/2016
- Endrich
- Endrich MI0430PT-50, 480x272 Pixel (1.5 KB, txt) - 26/11/2015
- Endrich MI0570ET-53, 800x480 Pixel (1.5 KB, txt) - 04/08/2016
- Endrich MI0570ET-53, 640x480 Pixel (1.5 KB, txt) - 04/08/2016
- Endrich MI0700AJT-5X, 800x480 Pixel (1.5 KB, txt) - 27/11/2015
- Endrich MI0700B1T, 800x480 Pixel (692 bytes, txt) - 04/08/2016
- Endrich MI0700S4T-50, 800x480 Pixel (1.5 KB, txt) - 26/11/2015
- Evervision
- Evervision VGG644804-6UFLWE, 640x480 Pixel (738 bytes, txt) - 04/08/2016
- Evervision VGG804806, 800x480 Pixel (762 bytes, txt) - 07/08/2015
- Evervision VGG804807, 800x480 Pixel (808 bytes, txt) - 17/11/2014
- InnoLux
- InnoLux G057VGE, 640x480 Pixel (752 bytes, txt) - 04/07/2014
- InnoLux G065VN01, 640x480 Pixel (753 bytes, txt) - 08/04/2015
- KOE
- KOE TX09D200-VM0BAA, 640x240 Pixel (758 bytes, txt) - 04/08/2016
- KOE TX14D11VM1, 320x240 Pixel (788 bytes, txt) - 04/08/2016
- KOE TX14D14VM1BPB, 640x480 Pixel (727 bytes, txt) - 13/05/2016
- KOE TX16D20, 640x240 Pixel (758 bytes, txt) - 04/08/2016
- KOE TX23D200VMOCPA, 800x480 Pixel (734 bytes, txt) - 04/08/2016
- KOE TX23D38VMOCPA, 800x480 Pixel (774 bytes, txt) - 04/08/2016
- M101NWWB
- M101NWWB R3, 1280x800 Pixel (766 bytes, txt) - 23/07/2015
- SEP
- SEP T056640480-AOTMC, 640x480 Pixel (735 bytes, txt) - 04/08/2016
- SGD
- SGD GKVGC1MNDK2A0, 1280x800 Pixel (825 bytes, txt) - 10/03/2015
- SGD GVTSA4TNBL4E0, 800x600 Pixel (752 bytes, txt) - 31/10/2014
- SGD GVTV57SNAD1E0, 640x480 Pixel (753 bytes, txt) - 17/02/2015
- SGD GVTW70CAG2C0, 800x480 Pixel (759 bytes, txt) - 16/04/2016
- SGD GVTW70SNAG2E0, 800x480 Pixel (754 bytes, txt) - 17/02/2015
- URT
- URT UMOH9113MD-5T, 1280x800 Pixel (732 bytes, txt) - 04/08/2016
- chefree
- chefree CH057DLCL, 640x480 Pixel (768 bytes, txt) - 04/08/2016
Usage
By downloading you accept our general terms and conditions.
Usage
By downloading you accept our general terms and conditions.
Variants
 |
efus™A9Xr2-V2-W13 NXP i.MX 6SoloX Cortex-A9 + Cortex-M4, 512MB RAM, 256MB Flash, 2x Gb Ethernet, 2x CAN, Audio, PCIe, Parallel 8bit Camera, Touch, LVDS, RGB, 0°C - +70°C, 5V Supply, Windows Embedded Compact 2013 SKU: efusA9Xr2-V2-W13 |
Request | ||
 |
efus™A9Xr2-V2-LIN NXP i.MX 6SoloX Cortex-A9 + Cortex-M4, 512MB RAM, 256MB Flash, 2x Gb Ethernet, 2x CAN, Audio, PCIe, Parallel 8bit Camera, Touch, LVDS, RGB, 0°C - +70°C, 5V Supply, Linux Buildroot/Yocto SKU: efusA9Xr2-V2-LIN |
Request | ||
|
efus™A9Xr2-V4-W13 NXP i.MX 6 Cortex-A9 - 1GHz + Cortex-M4 - 200MHz, 1GB DDR RAM, 256MB Flash, min. 4GB eMMC, WLAN/BT, 2x Ethernet, 2x CAN2.0, RGB+LVDS, Windows Embedded Compact 2013 SKU: efusA9Xr2-V4-W13 |
Request | ||
|
efus™A9Xr2-V4-LIN NXP i.MX 6SoloX Cortex-A9 + Cortex-M4, 512MB RAM, 1GB Flash, min. 4GB eMMC, 2x Gb Ethernet, 2x CAN, Audio, WLAN, BT, PCIe, analog/Parallel 8bit Camera, Touch, LVDS, RGB, 0°C - +70°C, 5V Supply, Linux Buildroot/Yocto SKU: efusA9Xr2-V4-LIN |
Request | ||
|
efus™A9Xr2-V5-LIN/-W13 NXP i.MX 6SoloX Cortex-A9 + Cortex-M4, 512MB RAM, 256MB Flash, Gb Ethernet, 2x CAN, Audio, WLAN, BT, PCIe, analog/Parallel 8bit Camera, Touch, LVDS, RGB, 0°C - +70°C, 5V Supply, Linux Buildroot/Yocto or Windows Embedded Compact 2013 SKU: efusA9Xr2-V5-LIN/-W13 |
Request | ||
|
efus™A9X-V8-W13 NXP i.MX 6SoloX Cortex-A9 + Cortex-M4, 512GB RAM, 512MB Flash, 1x Gb Ethernet, 2x CAN, Audio, WLAN, BT, PCIe, analog/Parallel 8bit camera, Touch, LVDS, RGB, 0°C - +70°C, 5V supply, Windows Embedded Compact 2013 SKU: efusA9X-V8-W13 |
Request | ||
Starterkits
|
Starterkit efus™A9X Linux efusA9X-V4-LIN, base board, cable kit, 7" EDT RGB TFT with resistive touch incl. adapter and cables, access data to documentation and software SKU: efusA9X-SKIT-LIN |
360,- € | ||
|
Starterkit efus™A9X Windows efusA9X-V4-W13, base board, cable kit, 7" EDT RGB TFT with resistive touch incl. adapter and cables, access data to documentation and software SKU: efusA9X-SKIT-WCE |
360,- € |
Software
|
Software .NET Drivers Driver package for retrofitting, consists of C# drivers for I²C/ SPI/ CAN, as well as the SPI driver in C++. SKU: WCE-DOTNET |
500,- € | ||
|
UpDate Software This program package allows a safe and easy update of the application program and the operating system via USB Stick or SD Card. SKU: WCE-UPDATE |
500,- € | ||
|
Boot Screen Shows the device's user a starting procedure while booting (BMP File). SKU: WCE-BOOTSCREEN |
500,- € | ||
|
Custom Kernel Creation of a customer-specific kernel. Windows CE components are set as the customer requests, as well as the registry entries (e.g. display). Customer-supplied software can also be added. SKU: WCE-CUSTIMAGE |
500,- € | ||
|
Failsafe Flash Filesystem (F3S) The Failsafe Flash Filesystem F3S offers transaction safety on file level and therefore guarantees the consistency of the data, even in case of a blackout or other interferences while writing. SKU: WCE-F3S |
1,000,- € | ||
|
Secure Boot as a Service The SBS (Secure Boot as a Service) includes the signing (protection against manipulation) and if necessary encryption (protection of intellectual property) by F&S Elektronik Systeme. SKU: Linux-SBS |
500,- € | ||
|
Display Customization (RGB or LVDS display under Linux) Creation of a DeviceTree (Buildroot or Yocto) for your F&S Board. The DeviceTree contains the appropriate entries for your display. SKU: EW-SW |
700,- € | ||
|
Display Customization (MIPI-DSI Display under Linux) Creation of a DeviceTree / kernel (Buildroot or Yocto) for your F&S Board. The DeviceTree / kernel contains the appropriate entries for your MIPI-DSI display. SKU: EW-SW-MIPI-DSI-Linux |
1,000,- € | ||
|
Display Customization (RGB orLVDS Display under Windows) Creation of a driver for the touch controller under WCE7 or WEC13 for your F&S board. SKU: EW-SW-RGB-LVDS-Windows |
500,- € |
Displays and Display Kits
|
7" RGB Display with resistive Touch 7" TFT (800x480) EDT ET070080DH6 SKU: B.LCD.15 |
120,- € | ||
|
7" RGB Display with PCAP Touch 7" TFT (800x480) Display Endrich MI0700AJT-54CP with capacitive Touch SKU: B.LCD.18 |
150,- € | ||
|
Displaykit RGB 2 7" WVGA Display with RGB interface and touch panel, connection cable (40pol film cable), display adapter and touch cable SKU: aSt-RGBKIT |
170,- € | ||
|
Displaykit 7" RGB - PCAP Touch 7" Display with RGB interface and capacitive touch panel, connection cable (50pol film cable) and display adapter. SKU: KIT-TFT-7RGB |
210,- € |
Touch Kits
|
Resistive Touch Kit For connecting a resistive Touch panel to F&S boards with 4-poles touch connector. SKU: SINTF-ADP-RESTOUCH |
35,- € | ||
|
PCAP Touch Kit for EDT Kit to connect an EDT PCAP touch panel SKU: ADP-EDTTOUCH2 |
35,- € |
Cables
|
50poles Film Cable Cable for 7" RGB Endrich Display (B.LCD.18) FFC cable, A50pol., pitch=0,5mm, l=200mm SKU: B.MKAB.41 |
10,- € | ||
|
LVDS Cable LVDS cable with JAE FI X30 on one side and open ends on the other side SKU: B.MKAB.53 |
22,- € |
Adapters
|
I2C Erweiterung Circuit for an external extension with GPIOs, AID, PWM and matrix keyboard. This external circuit is connected via I²C Bus. SKU: NDCU-ADP/I2C |
80,- € | ||
|
JTAG Debug Adapter To program Cortex-M4. SKU: ADP-CMSIS |
69,- € | ||
|
armStone™/ efus™/ PicoCore™ DVI Adapter Connects armStone™, efus™ or PicoCore™ to a DVI/ HDMI screen. SKU: aStone-ADP-DVI |
50,- € | ||
|
Adapter for Endrich iSi50 Displays Adapter to connect Endrich iSi50 displays to F&S boards SKU: aSt-ADP-MIT1 |
50,- € | ||
|
mPCIe Module with WLAN/BT mPCIe-Full-Mini Type F1 or mPCIe-Half-Mini Type H1 module with WLAN 2.4/ 5 GHz und BT5.0 LE SKU: ADP-mPCIe-WLAN |
40,- € |
Plug Connector
|
MXM-2 Connector For connecting efus™- or QBliss-modules via goldfinger contacts. SKU: B.MST.2R230PL.1 |
43,- € |
Workshops
|
Workshops Workshops for F&S Boards with Windows Embedded Compact or Linux - Beginner Workshops - Qt 5 - Asymmetric Multiprocessing - Secure Boot SKU: NDCU-WS1 |
Request | ||
|
Secure Boot as a Package Secure Boot as a Package contains a workshop, where you learn how to realize the topic Secure Boot. You will also receive a user Tool Software. SKU: WS-SBP |
500,- € | ||
Other Accessories
|
USB Stick USB Memory Stick with common memory size (2GB+) and imprinted F&S logo. The USB Stick was tested on all current F&S boards. SKU: USBSTICK.1 |
20,- € | ||
|
efus™ Latch Allows to mount efus™ modules on the base board. SKU: B.MST.VR.5 |
36,- € | ||
|
Patch Antenna Patch antenna for WLAN/ BT (2.4 GHz) to connect F&S modules with WLAN/ BT antenna socket SKU: B.ANT.5 |
10,- € |
Link to the Forum
You will always find support in our Forum.
Recent Contributions
|
20 Dec, 13:46 |
New Yocto Release fsimx6sx-Y2024.12 |
|
20 Dec, 13:45 |
New F&S Development Machine - Fedora36-arm32 |
|
20 Dec, 10:00 |
Howto initramfs with yocto on efusA7ULL |
|
19 Dec, 16:22 |
Repartitioning NAND Flash (via Yocto/ Patch) |
|
12 Dec, 09:21 |
SPIDEV probe function not called |
|
11 Dec, 12:16 |
CANscan: Powerful CAN Bus Testing and Communication Tool with Avalonia UI |
|
10 Dec, 09:13 |
request to introduce a github repo also for the toolchain with corresponding history |
|
05 Dec, 06:29 |
WEC 2013: How to close UDP Ports 137 and 138 / how to disable NetBIOS over TCP/IP |
|
04 Dec, 12:48 |
New i.MX8MP GPU Driver |
|
04 Dec, 09:32 |
Prevent efusA9 with WEC 2013 from sending Device Info |
| Easy, Functional.. | ..Universal, Small | |
|---|---|---|
|
efus™A9X is another compact and inexpensive module in efus™ form factor. It is perfectly suited for applications with numerous interfaces in medicine and industry. Easy Base BoardAlong with the attribute of an easy baseboard (EasyLayout), efus™ has a size of 47x62mm only and is therefore suitable for compact housings. The low power loss of only 2 Watt (typ.) makes it easy to cool the module. Innovative Applications Processorefus™A9X is based on a NXP single-core applications processor from the very successful i.MX 6 series and has a Cortex-A9, as well as a Cortex-M4 core. Cortex-M4 can be used for fast control and regulation functions or for processing fast interface protocols. Long-Term Availability to 20352D, 3D, NEON and FPU are available, ensuring software compatibility to other i.MX 6 applications processors. Another characteristic is the long-time availability to at least 2035. |
efus™A9X comes with up to 1GB DDR3L RAM and up to 1GB SLC NAND Flash. Up to 32GB eMMC are available additionally. Various InterfacesThe module offers interfaces like 2x Gigabit Ethernet, 4x Serial, USB2.0 Host/Device, 2x CAN, 2x I²C, 2x SPI, I2S Audio, 2x SDIO, PCIe, Camera (analog/digital), WLAN and BT, as well as high accuracy RTC (TXCO). The customized operating system (WEC 2013/ WEC7 or Linux) supports all interfaces, guaranteeing an easy software development without a deeper understanding of hardware. Audio Codec as well as touch controller are found on the base board. WLAN and BT with chip antenna or antenna socket can be offered as well. Of course, efus™A9X is pin compatible to efus™A9. |
